Lopolight 3nm 360 Degree Signalling Light White+IR Horizontal Mount Black
Lopolight 3nm 360 Degree Signalling Light White+IR Horizontal Mount Black
SKU:LOP-301-415-B
Out of stock
Regular price
$2,504.31 USD
Regular price
$0.00 USD
Sale price
$2,504.31 USD
Shipping calculated at checkout.
Quantity
Lopolight started out back in 2004, offering many solutions and neat combinations for all size boats and yachts. The tradition continues. Lopolight offers a full range of navigation lights dedicated for boats and yachts, resulting in an elegant, compact and precise solution with good value for money.
Product Features
2 lights (white & IR) stacked in one light body 3-lead connection 24VDC 2 lights (white & IR) stacked in one light body 3-lead connection 24VDC
Product Certification
This Navigation Light is certified by DNV, the Declaration of conformity and the certificates can be found on www.lopolight.com under Support
Product Specifications
| Attribute | Value |
|---|---|
| Approved to | IEC 60945 |
| Mounting | Horizontal |
| EAN | 5704438011656 |
| UPC Code | 879343011659 |
| Stock status | Made to order |
| Min. feed wire gauge | 0.5mm2 AWG22 |
| Light Color | White,IR |
| Intensity | >15cd |
| Visibility | 3nm |
| Materials | Black anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane |
| IP rating | IP68 |
| Connection | Plug connector |
| Current consumption (mA @ 24VDC) | 111 |
| Weight (Kg) | 0.76 Kg |
| Dimensions metric | See drawing |
| Dimensions imperial | See drawing |
| Operating temperature | -25¡C to 55¡C |
| Operating Voltage | 10-32VDC |
| Power draw (W) | 2,7 |
| Current consumption (mA @ 12VDC) | 0 |
| Vessel size | Over 50M |
| Weight (Oz) | 26.66 Oz |
