ALUMINUM ALLOY | TWIST LOCK SLEEVE |COMPACT HMS

Aluminium connector with 2 actions Twist Lock sleeve and Keylock system. The classic wide pear shape makes it suitable for belay with clove hitch. Can be used with all anchoring and belaying systems. Automatic sleeve makes it suitable for professional use. More compact and lighter than the traditional connector HMS and with a higher tensile strength. Equipped with Keylock system that prevents any snagging with the rope and in the bolts. High quality product completely developed and produced in Italy. Tested piece by piece. Old Part # 787MG0BDBKK,

Standards - EN 12275, EN 362/B, UIAA
Material - Alu Alloy
Type - Keylock
Main Axis Load - 23kN
Minor Axis Load - 8kN
Open Gate Load - /
Weight - 85g
Shape - H.M.S.

A. Length - 110mm
B. Width - 71.5mm
C. Body Diameter - 12mm
D. Eyelet Diameter - /
E. Gate Opening Diameter - 23mm

Sleeve - Twist Lock
