Blue Sea 8505 AC Main + Branch A-Series Toggle Circuit Breaker Panel (230V) - Main + 3 Position
Blue Sea 8505 AC Main + Branch A-Series Toggle Circuit Breaker Panel (230V) - Main + 3 Position
SKU:BLU-8505
Out of stock
Regular price
$564.49 USD
Regular price
$727.05 USD
Sale price
$564.49 USD
Unit price
/
per
Shipping calculated at checkout.
230V AC Main + Branch A-Series Toggle Circuit Breaker Panel
PN: 8505
White Switches
(1) 16A Double Pole Circuit Breaker Installed
(3) 8A Single Pole Circuit Breakers Installed
(1) 8247 AC Digital Multimeter w/ Alarm
Features:
PN: 8505
White Switches
Features:
- Red reverse polarity indicating LED
- All hot, neutral and safety ground buses installed, fully pre-wired
- All circuit label positions are backlit on standard panels - No kit required
- "ON" indicating LEDs installed in all circuit positions
- Maximum panel amperage - 50 Amperes
- MIL-C-5541C or equivalent immersion undercoating for lifetime corrosion resistance
- Two-part polyurethane slate gray finish
- Heavy 1/8" aluminum 5052 alloy
- Industry standard height and width
- Countersunk mounting holes throughout
- Detailed installation instructions and cutout template included
- Includes set of 30 common Large Format Labels
- Over 500 individual Labels available
WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more infomation go to www.P65Warnings.ca.gov
Couldn't load pickup availability
Product Literature
