BEP AC Circuit Breaker Panel with Digital Meters, 16SP 2DP AC120V ACSM Stainless Steel Horizontal
BEP AC Circuit Breaker Panel with Digital Meters, 16SP 2DP AC120V ACSM Stainless Steel Horizontal
SKU:BEP-900-AC4-ACSM-110
Out of stock
Regular price
$1,512.31 USD
Regular price
$2,032.55 USD
Sale price
$1,512.31 USD
Unit price
/
per
Shipping calculated at checkout.
AC Circuit Breaker Panel with Digital Meters, 16SP 2DP AC120V ACSM Stainless Steel Horizontal
Features:
- Supplied with tranducer
- Reverse polarity indicator
- Double pole mains input CBs with side lockout
- Digital meter shows volts, amps and frequency
- LED wired to indicate live panel with mains breaker either on or off
- AC source selector ensures no cross over between AC inputs (ship or shore power)
Specifications:
- Total Positions: 16 Loads + 2 Inputs
- Circuit Breakers: 5x 10A, 7x 15A, 2x 20A, 1x 25A, 1x 30A + 1x 30A, 1x 80A
- Nominal Voltage: 110V AC
- Maximum Amperage: 80A
- Dimensions: 7.9" X 13.9" X 2.5"
- Neg Bus: IS-6MM-2
WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more infomation go to www.P65Warnings.ca.gov
NOTE: This product is a special order direct from the manufacturer and could have a lead-time in excess of 4 weeks. Contact Us for a more accurate time estimate.
